DGS-3312SR Layer 3 Gigabit Switch
115
14
PORT MIRRORING COMMANDS
The port mirroring commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table.
Command Parameters
config mirror port <port> [add | delete] source ports <portlist> [rx | tx | both]
enable mirror
disable mirror
show mirror
Each command is listed, in detail, in the following sections.
NOTE: As a stand-alone switch or as a master switch in a switch stack,
the switch number will be referred to as 15 for all configurations, graphs
and tables.
config mirror port
Purpose
Used to configure a mirror port source port pair on the switch.
Syntax
config mirror port <port> add source ports <portlist> [rx | tx |
both]
Description This command allows a range of ports to have all of their traffic
also sent to a designated port, where a network sniffer or other
device can monitor the network traffic. In addition, you can specify
that only traffic received by or sent by one or both is mirrored to
the Target port.
Parameters
port <port> This specifies the Target port (the port where
mirrored packets will be sent). The port list is specified by listing
the lowest switch number and the beginning port number on that
switch, separated by a colon. Then the highest switch number,
and the highest port number of the range (also separated by a
colon) are specified. The beginning and end of the port list range
are separated by a dash. For example, 1:3 specifies switch
number 1, port 3. 2:4 specifies switch number 2, port 4. 1:3-2:4
specifies all of the ports between switch 1, port 3 and switch 2,
port 4 in numerical order.
add source ports – The port or ports being mirrored. This cannot
include the Target port.
<portlist> This specifies a range of ports that will be
mirrored. That is, the range of ports in which all traffic will be
copied and sent to the Target port. The port list is specified
by listing the lowest switch number and the beginning port
number on that switch, separated by a colon. Then the
