DGS-3312SR Layer 3 Gigabit Switch
131
show link_aggregation
Parameters
group_id <value 1-6> Specifies the group ID. The switch allows up
to 6 link aggregation groups to be configured. The group number
identifies each of the groups.
algorithm Allows you to specify the display of link aggregation by
the algorithm in use by that group.
Restrictions None.
Example usage:
To display Link Aggregation configuration:
DGS-3312SR:4#show link_aggregation
Command: show link_aggregation
Link Aggregation Algorithm = MAC-source-dest
Group ID : 1
Master Port : 2:10
Member Port : 1:5-1:10,2:10
Active Port:
Status : Disabled
Flooding Port : 1:5
DGS-3312SR:4
config lacp_ports
Purpose Used to configure settings for LACP compliant ports.
Syntax
config lacp_ports <portlist> mode [active | passive]
Description This command is used to configure ports that have been
previously designated as LACP ports (see create
link_aggregation).
Parameters
<portlist> Specifies a range of ports to be configured. The port
list is specified by listing the lowest switch number and the
beginning port number on that switch, separated by a colon. Then
the highest switch number, and the highest port number of the
range (also separated by a colon) are specified. The beginning
and end of the port list range are separated by a dash. For
example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between
switch 1, port 3 and switch 2, port 4 in numerical order.
mode – Select the mode to determine if LACP ports will process
LACP control frames.
