DGS-3312SR Layer 3 Gigabit Switch

117

config mirror delete

port 4 − in numerical order.

delete source port – Adding this parameter will delete source ports

according to ports entered using the <portlist>.

 <portlist> − This specifies a range of ports that will be

mirrored. That is, the range of ports in which all traffic will be

copied and sent to the Target port. The port list is specified

by listing the lowest switch number and the beginning port

number on that switch, separated by a colon. Then the

highest switch number, and the highest port number of the

range (also separated by a colon) are specified. The

beginning and end of the port list range are separated by a

dash. For example, 1:3 specifies switch number 1, port 3. 2:4

specifies switch number 2, port 4. 1:3-2:4 specifies all of the

ports between switch 1, port 3 and switch 2, port 4 − in

numerical order.

rx − Allows the mirroring of only packets received by (flowing into)

the port or ports in the port list.

tx − Allows the mirroring of only packets sent to (flowing out of) the

port or ports in the port list.

both − Mirrors all the packets received or sent by the port or ports

in the port list.

Restrictions Only administrator-level users can issue this command.

Example usage:

To delete the mirroring ports:

DGS-3312SR:4#config mirror port 1:5 delete source port 1:1-1:5 both

Command: config mirror 1:5 delete source 1:1-1:5 both

Success.

DGS-3312SR:4#

enable mirror

Purpose Used to enable a previously entered port mirroring configuration.

Syntax

enable mirror

Description

This command, combined with the disable mirror command

below, allows you to enter a port mirroring configuration into the

switch, and then turn the port mirroring on and off without having

to modify the port mirroring configuration.

Parameters None.
