DGS-3312SR Layer 3 Gigabit Switch

202

show 802.1x auth_configuration

Parameters

ports <portlist> − Specifies a range of ports. The port list is specified

by listing the lowest switch number and the beginning port number on

that switch, separated by a colon. Then the highest switch number,

and the highest port number of the range (also separated by a colon)

are specified. The beginning and end of the port list range are

separated by a dash. For example, 1:3 specifies switch number 1,

port 3. 2:4 specifies switch number 2, port 4. 1:3-2:4 specifies all of

the ports between switch 1, port 3 and switch 2, port 4 − in numerical

order.

The following details what is displayed:

802.1x Enabled/Disabled − Shows the current status of 802.1x

functions on the switch.

Authentication Protocol: Radius_Eap − Shows the authentication

protocol suite in use between the switch and a Radius server.

Port number − Shows the physical port number on the switch.

Capability: Authenticator/None − Shows the capability of 802.1x

functions on the port number displayed above. There are two 802.1x

capabilities that can be set on the switch: Authenticator and None.

AdminCtlDir: Both/In − Shows whether a controlled Port that is

unauthorized will exert control over communication in both receiving

and transmitting directions, or just the receiving direction.

OpenCtlDir: Both/In − Shows whether a controlled Port that is

unauthorized will exert control over communication in both receiving

and transmitting directions, or just the receiving direction.

Port Control: ForceAuth/ForceUnauth/Auto − Shows the

administrative control over the port’s authorization status. ForceAuth

forces the Authenticator of the port to become Authorized.

ForceUnauth forces the port to become Unauthorized.

QuietPeriod − Shows the time interval between authentication failure

and the start of a new authentication attempt.

TxPeriod − Shows the time to wait for a response from a supplicant

(user) to send EAP Request/Identity packets.

SuppTimeout − Shows the time to wait for a response from a

supplicant (user) for all EAP packets, except for the Request/Identity

packets.

ServerTimeout − Shows the length of time to wait for a response from

a RADIUS server.

MaxReq − Shows the maximum number of times to retry sending

packets to the supplicant.
