11D-Link DCS-5220 User Manual
Section 2 - Installation
Turn on the computer and Insert the D-Link DCS-5220 Driver CD in the CD-ROM drive. The step-by-step instructions that
follow are shown in Windows
®
XP. The steps and screens are similar for the other Windows
®
operating systems.
If the CD Autorun function does not automatically start on your computer, click Windows
®
Start > Run. In the Run
command box type “D:\DCS5220.exe”, where D: represents the drive letter of your CD-ROM. If it does start, proceed
to the next screen.
Software Installation
Click Installation Wizard
