74D-Link DCS-5220 User Manual
Section 3 - Configuration
Camera Configurations
When you log in for the rst time, you should congure this application software to connect the DCS-5220 in Conguration
Menu > Camera Congurations, shown in the gure below. You will need the admin (administrator) password of the
camera in order to run the conguration.
Once you click Conguration Menu > Camera Congurations for setting each camera, all recording processes will
be stopped indicated by a warning window popped up in advance to keep you informed.
