9D-Link DCS-5220 User Manual
Section 1 - Product Overview
Hardware Installation
Connect an Ethernet cable to the Ethernet connector located on the Internet Camera’s
back panel and attach it to the network.
Note: It is required that an Ethernet cable is used during initial setup. Once your wireless
configuration is set, you may disconnect the Ethernet cable and begin communicating
wirelessly with your DCS-5220.
Attach the external power supply to the DC power input connector located on the
Internet Camera’s back panel (labeled DC 12V) and connect it to an AC power
outlet.
