89D-Link DCS-5220 User Manual
Section 3 - Configuration
Schedule in Event Mode
You can select to record in Event mode or Continuous mode by the Schedule mode selector as shown in the gure
below. There are two types of event recording. Please refer to the following two sections for more information.
Motion Detection
As shown below, you can check the windows that you would like to record while the motion detection is triggered.
Digital Input
In the gure below, there are four conditions for the digital input. Check the condition that you would like to record
while the condition triggers.
Note: The Digital Input is not available for the DCS-5220 camera.
