D-Link DCS-5220 [18/153] Network settings

18D-Link DCS-5220 User Manual

Section 3 - Conﬁguration

Users can congure the Network Settings for the camera

by entering the IP address, Subnet mask, Default router IP,

Primary DNS, and Secondary DNS. The option to reset IP

address at boot is automatically selected. If you would like

to keep your IP address settings, make sure to uncheck this

box.

Note: These settings can also be configured on the

Advanced > Network page when conﬁguring the camera

via a Web Browser.

Click Next

Network Settings
