D-Link DCS-5220 [127/153] Play from realplayer

127D-Link DCS-5220 User Manual

Section 4 - Security

The following steps are based on a Nokia 6630 cell phone.

Play from RealPlayer

Press the Menu button and select Media

Select Open

Select RealPlayer
