D-Link DCS-5220 [16/153] Configuration

16D-Link DCS-5220 User Manual

Section 3 - Conﬁguration

Installation Wizard

The following options are available on the Installation Wizard

screen by clicking on the corresponding tab:

Conﬁguration

This section will show you how to congure your new D-Link Wireless PT Internet Camera using the D-Link Installation

Wizard.

Click Setup
