D-Link DCS-5220 [71/153] Application layout and functionalities

71D-Link DCS-5220 User Manual

Section 3 - Conﬁguration

Application Layout and Functionalities

This section demonstrates a global view of the monitor program, shown below. The components of the monitor

tool will be introduced in detail in the following sections.

Misc. Functions

Channel Area

Layout Area

Hard Disk Status

Video Area

Common Control Area

DI/DO Control

Alert Message
