13D-Link DCS-5220 User Manual

Section 2 - Installation

The InstallShield will install the software in the following folder. To

install the software into a different folder, click Browse and select

another folder.

Select the Program folder that Setup will add program icons to.

You may type a new folder name, or select one from the existing

folders list.

Click Next
