63D-Link DCS-5220 User Manual

Section 3 - Conﬁguration

Enter your User Name and Company Name information.

Note: This User Name is not the User Name to log into the IP

surveillance program.

Click Next

You must setup the administrator’s password in order to proceed.

Input and conrm your password in the window shown below.
