10-013816-01EN, Rev. 2, June 2020

Overview 31

Figure 1-11 Short yoke with minimum (31.75 mm) wedge width setting

It is important to ensure that both yoke arms are properly aligned with the center of

the yoke pivoting beam. Having unaligned yoke arms could result in the probe

flipping during the inspection, compromising data acquisition. For correct and

incorrect alignment examples, see Figure 1-12 on page 32 and Figure 1-13 on page 32

respectively.

IMPORTANT
