10-013816-01EN, Rev. 2, June 2020

Chapter 130

Figure 1-9 Long yoke with minimum (31.75 mm) wedge width setting

The long yoke has a two-button position as shown by the dotted lines.

Figure 1-10 Short yoke with maximum (55 mm) wedge width setting

NOTE
