12.Technical Specifications
Voltage V 230 ~ 50 Hz 110 ~ 50 Hz
Fuse protection min. A 10 16
Motor capacity W 1800 1620
Degree of protection IP 20 20
Protection class I I
No-load speed (cutterblock) min
-1
9800 9100
Feed rate m/min 7.5 7.5
Depth of cut maximum mm 3 3
Work piece thickness minimum
maximum
mm
mm
5
152
5
152
Work piece width minimum
maximum
mm
mm
19
330
19
330
Work piece length minimum mm 356 356
Dimensions depth (tables folded up)
width
height
mm
mm
mm
350
585
495
350
585
495
Dimensions depth (thicknessing table)
width (thicknessing table)
mm
mm
600
370
600
370
Weight kg 35 35
Permissible ambient operating temperature range
Permissible transport and storage temperature range
°C
°C
0 to +40
0 to +40
0 to + 40
0 to + 40
Noise emission values according to EN 61029-1*
A-sound pressure level L
pA
A-sound power level L
WA
Uncertainty K
dB (A)
dB (A)
dB (A)
94
107
4
94
107
4
Dust collector inner diameter of dust extraction connector
outer diameter of dust extraction connector
air flow volume
vacuum at suction connector
air speed at suction connector
mm
mm
m
3
/h
Pa
m/s
64
102
460
530
20
64
102
460
530
20
* The values stated are emission values and as such do not necessarily constitute values which are safe for the workplace.
Although there is a correlation between emission levels and environmental impact levels, whether further precautions are neces
-
sary cannot be derived from this. Factors influencing the actually present environmental impact level in the workplace include the
characteristics of the work area and other noise sources, i.e. the number of machines and other neighbouring work processes.
Also, permissible workplace values may vary from country to country. This information is intended to assist the user in his estimate
of hazards and risks.
