92 System Configuration



To adjust the angle of the INTELLIGENT EYE sensor

• You can adjust the angle of the INTELLIGENT

EYE sensor to increase the detection area.

(Adjustable angle: 15° to right and left of centre)

• Gently push and slide the sensor to adjust the

angle.

• After adjusting the angle, wipe the sensor gently

with a clean cloth, being careful not to scratch the

sensor.

“INTELLIGENT EYE” is useful for Energy Saving

Notes on “INTELLIGENT EYE”

CAUTION

15°15°

INTELLIGENT EYE

sensor

oving the sensor to the left Moving the sensor to the right



Energy saving operation

• Change the temperature –2°C in heating / +2°C in cooling / +1°C in dry mode from set temperature.

• Decrease the air flow rate slightly in fan operation. (In FAN mode only)

• Application range is as follows.

• Sensor may not detect moving objects further than 5m away. (Check the application range)

• Sensor detection sensitivity changes according to indoor unit location, the speed of passersby, temperature range, etc.

• The sensor also mistakenly detects pets, sunlight, fluttering curtains and light reflected off of mirrors as passersby.

• INTELLIGENT EYE operation will not go on during powerful operation.

• Night set mode will not go on during you use INTELLIGENT EYE operation..

• Do not place large objects near the sensor.Also keep heating units or humidifiers outside the sensor’s detection area.

This sensor can detect objects it shouldn’t as well as not detect objects it should.

• Do not hit or violently push the INTELLIGENT EYE sensor. This can lead to damage and malfunction.

80°

50°

Horizontal angle 100°

(Top View)

Vertical angle 80°

(Side View)
