SiENBE04-401A Specifications
Specifications 27
50Hz 230V
Note: MAX. interunit piping length: 15m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTXS35CVMB(9)(8)
Outdoor Units
RXH35CVMB9
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 3.15 (1.4~3.8) 3.6 (1.4~5.0)
Btu/h 10,750 (4,750~12,950) 12,300 (4,750~17,050)
kcal/h 2,710 (1,200~3,270) 3,100 (1,200~4,300)
Moisture Removal L/h 1.7 —
Running Current (Rated) A 4.9 4.9
Power Consumption
Rated (Min.~Max.)
W 1,045 (460~1,425) 1,055 (405~1,900)
Power Factor % 92.7 93.6
COP (Rated) W/W 3.01 3.41
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 9.5
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Units FTXS35CVMB(9)(8)
Front Panel Color White
Air Flow Rate
mł/min
(cfm)
H 7.7 (272) 8.1 (286)
M 6.0 (212) 6.7 (237)
L 4.4 (155) 5.3 (187)
SL 3.8 (134) 4.6 (162)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325
Weight kg 7.5
Gross Weight kg 11
Operation
Sound
H/M/L/SL dBA 39 / 33 / 26 / 23 39 / 34 / 29 / 26
Sound Power H dBA 57 57
Outdoor Units RXH35CVMB9
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23NXD#A
Motor Output W 600
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant
Type R-410A
Charge kg 1.01
Air Flow Rate
mł/min
(cfm)
H
27.5 (972) 23.5 (830)
L
— (—) — (—)
Fan
Type Propeller
Motor Output W 25
Running Current (Rated) A 4.72 4.72
Power Consumption (Rated) W 1,005 1,015
Power Factor % 92.6 93.5
Starting Current A 4.9
Dimensions (H×W×D) mm 560×695×265
Packaged Dimensions (H×W×D) mm 599×824×337
Weight kg 33
Gross Weight kg 38
Operation
Sound
H/L dBA 48 / — 48 / —
Sound Power H dBA 63 63
Drawing No. C:3D044448
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
