SiENBE04-401A Outdoor Unit / RK(X)H-C, ARK(X)H-C, R(Y)N-C
Removal Procedure 203
Step Procedure Points
6
Remove the 2 screws
for removing the fan
motor.
7
Remove the fan motor.
Fan motor
(R4053)
