SiENBE04-401A Indoor Unit
Removal Procedure 151
1.2 Removal of Front Grille
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1. Opening and closing of
service cover
1
Remove a service
cover mounting screw.
Open service cover
upward
A switch for field setting is
not provided in particular.
Connection
wires
(R2516)
