Specifications SiENBE04-401A
34 Specifications
1.2.3 Non-lnverter Models
50Hz 230V
Note: MAX. interunit piping length: 15m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTYN20CVMB9 FTYN25CVMB9
Outdoor Units
RYN20CVMB9 RYN25CVMB9
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.0 2.6 2.25 2.85
Btu/h 6,800 8,850 7,650 9,700
kcal/h 1,720 2,240 1,940 2,450
Moisture Removal L/h 0.9 — 1.2 —
Running Current (Rated) A 3.3 4.0 3.7 4.4
Power Consumption
Rated (Min.~Max.)
W 620 760 700 835
Power Factor % 81.7 82.6 82.3 82.5
COP (Rated) W/W 3.23 3.42 3.21 3.41
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTYN20CVMB9 FTYN25CVMB9
Front Panel Color White White
Air Flow Rate
mł/min
(cfm)
H 7.7 (272) 7.8 (275) 7.7 (272) 7.8 (275)
M 5.9 (208) 6.5 (230) 5.9 (208) 6.5 (230)
L 4.2 (148) 5.3 (187) 4.2 (148) 5.3 (187)
SL————
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Auto 5 Steps, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38 / 32 / 26 / — 38 / 33 / 28 / — 38 / 32 / 26 / — 38 / 33 / 28 / —
Sound Power H dBA 56 56 56 56
Outdoor Units RYN20CVMB9 RYN25CVMB9
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 0.79 0.79
Air Flow Rate mł/min (cfm)
H 29 (1,025) 25.5 (901) 29 (1,025) 25.5 (901)
L — (—) — (—) — (—) — (—)
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Rated) A 3.12 3.82 3.52 4.22
Power Consumption (Rated) W 580 720 660 795
Power Factor % 80.8 81.9 81.5 81.9
Starting Current A 4.0 4.4
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (H×W×D) mm 599×824×337 599×824×337
Weight kg 31 31
Gross Weight kg 36 36
Operation
Sound
H/L dBA 46 / — 47 / — 46 / — 47 / —
Sound Power H dBA 61 62 61 62
Drawing No. 3D044452 3D044453
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
