![Daikin RXS25C2VMB [215/246] Remove the reactor](/img/pdf.png)
Daikin RXS25C2VMB [215/246] Remove the reactor
![Daikin ARKS20CVMB [215/246] Remove the reactor](/views2/1773639/page215/bgd7.png)
Outdoor Unit / RK(X)H-C, ARK(X)H-C, R(Y)N-C SiENBE04-401A
206 Removal Procedure
3. Remove the reactor.
1
The reactor can be
released by removing
the screw.
Step Procedure Points
Reactor
(R4060)
(R4061)
