SiENBE04-401A Instruction
System Configuration 81
ATTENTION
To operate the remote control
• To use the remote control, aim the
transmitter at the indoor unit. If there is
anything to block signals between the unit
and the remote control, such as a curtain,
the unit will not operate.
• Do not drop the remote control. Do not get it
wet.
• The maximum distance for communication is
about 7m.
To fix the remote control holder on the wall
1. Choose a place from where the signals
reach the unit.
2. Fix the holder to a wall, a pillar, or similar
location with the screws procured locally.
3. Place the remote control in the remote
control holder.
About remote control
• Never expose the remote control to direct sunlight.
• Dust on the signal transmitter or receiver will reduce the sensitivity. Wipe off dust with soft cloth.
• Signal communication may be disabled if an electronic-starter-type fluorescent lamp (such as inverter-type lamps) is in the
room. Consult the shop if that is the case.
• If the remote control signals happen to operate another appliance, move that appliance to some-where else, or consult the
shop.
Receiver
Remote controller
holder
Set.
z
To remove, pull it upwards.
