Instruction SiENBE04-401A
86 System Configuration
Notes on flaps and louvres angles
To adjust the vertical blades (louvres)
Hold the knob and move the louvers.
(You will find a knob on the left-side and the right-side blades.)
• When “
SWING button
” is selected, the flaps swinging range depends
on the operation mode. (See the figure.)
ATTENTION
• Always use a remote control to adjust the flaps angle. If you attempt to
move it forcibly with hand when it is swinging, the mechanism may be
broken.
• Be careful when adjusting the louvres. Inside the air outlet, a fan is
rotating at a high speed.
0º
25º
5º
30º
When stop operation
Upper limit in cooling
Lower limit in cooling
When stop operation
Upper limit in heating
Lower limit in heating
In DRY mode or COOL mode
In HEAT or FAN mode
