Daikin RXS25C2VMB [166/246] Remove a screw on the electrical box
![Daikin ARKS25CVMB [166/246] Remove a screw on the electrical box](/views2/1773639/page166/bga6.png)
SiENBE04-401A Indoor Unit
Removal Procedure 157
5
Remove a screw on the
terminal board.
The electrical box can be
removed instead of
disengaging the terminal
board.
6
Remove a screw on the
electrical box.
Step Procedure Points
