Daikin RXS25C2VMB [177/246] Remove a screw on the left side plate
![Daikin ARXS25CVMB [177/246] Remove a screw on the left side plate](/views2/1773639/page177/bgb1.png)
Indoor Unit SiENBE04-401A
168 Removal Procedure
4
Remove the motor and
fan rotor.
5
Remove a screw on the
left side plate.
Step Procedure Points
Disengage a hook from the backward
(R2562)
