![Daikin RXS20CVMB [23/246] Specifications](/views2/1773639/page23/bg17.png)
Specifications SiENBE04-401A
14 Specifications
50Hz 230V
Note: MAX. interunit piping length: 20m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units FTKS20CAVMB FTKS25CAVMB FTKS35CAVMB
Outdoor Units RKS20C2VMB RKS25C2VMB RKS35C2VMB
Capacity
Rated (Min.~Max.)
kW 2.0 (1.3~3.0) 2.5 (1.3~3.0) 3.4 (1.4~3.8)
Btu/h 6,800 (4,450~10,250) 8,550 (4,450~10,250) 11,600 (4,750~12,950)
kcal/h 1,720 (1,120~2,580) 2,150 (1,120~2,580) 2,920 (1,200~3,270)
Moisture Removal L/h 0.9 1.2 1.9
Running Current (Rated) A 2.8 3.9 4.9
Power Consumption
Rated (Min.~Max.)
W 500 (300~980) 695 (300~980) 1,060 (300~1,300)
Power Factor % 79.6 79.3 94.3
COP (Rated) W/W 4.00 3.60 3.21
Piping
Connections
Liquid mm φ 6.4 φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0 φ 18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTKS20CAVMB FTKS25CAVMB FTKS35CAVMB
Front Panel Color White White White
Air Flow Rate
mł/min
(cfm)
H 7.7 (272) 7.7 (272) 7.7 (272)
M 5.9 (208) 5.9 (208) 6.0 (212)
L 4.2 (148) 4.2 (148) 4.4 (155)
SL 3.6 (127) 3.6 (127) 3.8 (134)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 18 18 18
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40
Power Factor % 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325 258×834×325
Weight kg 7.5 7.5 7.5
Gross Weight kg 11 11 11
Operation
Sound
H/M/L/SL dBA 38 / 32 / 25 / 22 38 / 32 / 25 / 22 39 / 33 / 26 / 23
Sound Power H dBA 56 56 57
Outdoor Units RKS20C2VMB RKS25C2VMB RKS35C2VMB
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600 600
Refrigerant
Oil
Type FVC50K FVC50K FVC50K
Charge L 0.375 0.375 0.375
Refrigerant
Type R-410A R-410A R-410A
Charge kg 0.80 0.80 1.00
Air Flow Rate
mł/min
(cfm)
H 34 (1,201) 34 (1,201) 31.3 (1,105)
L 24.8 (876) 24.8 (876) 22.4 (791)
Fan
Type Propeller Propeller Propeller
Motor Output W 31 31 35
Running Current (Rated) A 2.62 3.72 4.72
Power Consumption (Rated) W 460 655 1,020
Power Factor % 76.3 76.6 94.0
Starting Current A 3.5 4.4 5.4
Dimensions (H×W×D) mm 550×765×285 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363 589×882×363
Weight kg 30 30 32
Gross Weight kg 35 35 38
Operation
Sound
H / L dBA 46 / 43 46 / 43 47 / 44
Sound Power H dBA 61 61 62
Drawing No. 3D050947 3D050949 3D050951
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
