Indoor Unit SiENBE04-401A
160 Removal Procedure
4
Disengage the four
knobs on the back of
the signal receiver
PCB.
5
Signal receiver PCB
Step Procedure Points
PC Board
(R2538)
Knob
(R2539)
LED1
(Green)
LED2
(Yellow)
LED3
(Red)
SW7
ON/OFF button
Thermistor
INTELLIGENT EYE
sensor PCB
S35
S26
S27
S36
