SiENBE04-401A Outdoor Unit / RK(X)S-C, ARK(X)S-C
Removal Procedure 175
4. Remove the right side
panel.
1
Loosen the 2 screws on
the rear side.
2
Loosen the 3 screws on
the right side.
3
Loosen the screw and
lift the connection port
to remove.
Step
Procedure Points
Right side panel
