SiENBE04-401A Specifications
Specifications 23
50Hz 230V
Note: MAX. interunit piping length: 20m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units ATXS35CVMB(9)
Outdoor Units
ARXS35CVMB
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 3.4 (1.4~3.8) 4.0 (1.4~5.0)
Btu/h 11,600 (4,750~12,950) 13,650 (4,750~17,050)
kcal/h 2,920 (1,200~3,270) 3,440 (1,200~4,300)
Moisture Removal L/h 1.9 —
Running Current (Rated) A 4.9 5.4
Power Consumption
Rated (Min.~Max.)
W 1,060 (300~1,300) 1,170 (310~1,590)
Power Factor % 94.3 95.4
COP (Rated) W/W 3.21 3.42
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 9.5
Drain mm φ18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Units ATXS35CVMB(9)
Front Panel Color White
Air Flow Rate
mł/min
(cfm)
H 7.7 (272) 8.1 (286)
M 6.1 (215) 6.7 (237)
L 4.4 (155) 5.3 (187)
SL 3.8 (134) 4.6 (162)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.6 96.6
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185
Packaged Dimensions (H×W×D) mm 258×834×325
Weight kg 7.5
Gross Weight kg 11
Operation
Sound
H/M/L/SL dBA 39 / 33 / 26 / 23 39 / 34 / 29 / 26
Sound Power H dBA 57 57
Outdoor Units ARXS35CVMB
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23NXD#A
Motor Output W 600
Refrigerant
Oil
Type FVC50K
Charge L 0.375
Refrigerant
Type R-410A
Charge kg 1.00
Air Flow Rate mł/min (cfm)
H 31.3 (1,105) 28.1 (992)
L 22.4 (791) 22.4 (791)
Fan
Type Propeller
Motor Output W 35
Running Current (Rated) A 4.72 5.22
Power Consumption (Rated) W 1,020 1,130
Power Factor % 94.0 94.1
Starting Current A 5.4
Dimensions (H×W×D) mm 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363
Weight kg 32
Gross Weight kg 38
Operation
Sound
H/L dBA 47 / 44 48 / 45
Sound Power H dBA 62 63
Drawing No. 3D044253B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
