SiENBE04-401A Outdoor Unit / RK(X)H-C, ARK(X)H-C, R(Y)N-C
Removal Procedure 211
4
Loosen the screw and
remove the four way
valve coil.
Step Procedure Points
Four way valve coil
(R4071)
(R4072)
