Outdoor Unit / RK(X)S-C, ARK(X)S-C SiENBE04-401A
188 Removal Procedure
4
Loosen the 4 screws.
5
Undo the 3 hooks on
the upper side.
6
Lift and pull out the
PCB.
Step
Procedure Points
Hooks
