Outdoor Unit / RK(X)H-C, ARK(X)H-C, R(Y)N-C SiENBE04-401A
200 Removal Procedure
4
Remove the terminal
board cover.
5
Lift and remove the
electrical box.
Step Procedure Points
(R4045)
(R4046)
