Indoor Unit SiENBE04-401A
164 Removal Procedure
7
Lift and remove heat
exchanger. Caution
When removing or re-
installing heat exchanger, be
sure to wear protective
gloves or wrap heat
exchanger with cloths. (Fins
can cut fingers.)
Step Procedure Points
