103 / 322
7.2.3 Configuring queue weights
command
describe
CLI mode
qos qosprofile (qp0| qp1| qp2|
qp3| qp4| qp5| qp6| qp7)
weight <1-127>
Configure the weight of each
priority queue
Interface
configuration mode
no qos qosprofile (qp0| qp1|
qp2| qp3| qp4| qp5| qp6| qp7)
weight
The weight of the recovery
queue is configured as the
default configuration
Interface
configuration mode
Queue weight is the number of packets forwarded by a priority queue when polling and
forwarding. Therefore, when configuring the queue weight, it should be noted that the weight of
the low priority queue does not exceed the weight of the high priority queue。
7.2.4 Configure the mapping relationship between
DSCP and QosProfile
command
describe
CLI mode
qos dsc-map-qp <0-63> qosprofile
{qp0|qp1|qp2|qp3|qp4|qp5|qp6|qp7}
Mapping relations between
DSCP and qosprofile。
Global
configuration mode
no qos dscp-map-qp <0-63>
Restoring the mapping
between DSCP and qosprofile
is the default configuration
。
Global
configuration mode
7.2.5 Configuring port QoS
QoS policy configuration steps: define class, define policy action, application strategy。
Define a class and define a set of flow classification rules：
A total of 802.1p priority, DSCP, ACL three flow classification rules, a class can only use a
set of flow classification rules, a group of flow classification rules can be used by multiple class.
The default configuration does not match any rules。
command
describe
CLI mode
qos class <1-256> name
WORD
Naming a specified class
Global
configuration
mode
qos class <1-256> match cos
<0-7> (<0-7>…)
Define a matching 802.1p priority
rule, which can configure 8 rules at
Global
configuration
