149 / 322
no ring <1-32> wtb-time
Restore ERPS ring WTB
default time
ERPS mode
ring <1-32> raps-send-time
<1-10>
Configuring ERPS ring
protocol packet delivery time
ERPS mode
no ring <1-32> raps-send-time
Restore ERPS ring protocol
message default sending time
ERPS mode
ring <1-32> (enable|disable)
Turn on or off the ERPS ring
ERPS mode
ring <1-32> forced-switch
IFNAME
Forced switching ERPS ring
port
ERPS mode
ring <1-32> clear forced-switch
Forced handoff of clear ERPS
ring
ERPS mode
ring <1-32> manual-switch
IFNAME
Manually switch the ERPS
ring port
ERPS mode
ring <1-32> clear manual-switch
Manual switching to clear
ERPS ring
ERPS mode
ring <1-32> clear recovery
Manual restoration of ERPS
loop's non recoverable
behavior or manual recovery
prior to WTR/WTB expiration
ERPS mode
show erps
Display all the ERPS instances
and loops in the device
Privileged mode
show erps <1-8>
Display device single ERPS
instance and loop details
Privileged mode
10.6 Typical use of ERPS
10.6.1 Example of single ring
The following diagram, SW1, SW2 and SW3 nodes constitute a single ERPs ring ring1, 1, 3
ports of each node as the ERPs ring ring port, protocol VLAN is 2, 3, 4 VLAN data, the SW1
node is RPL owner node, SW2 node to the RPL node of neighbor, SW1 and SW2 between the link
RPL link。
