95 / 322
description WORD
configuration by name
configuration mode
no voice-vlan default-oui
Delete all defualt OUI
configurations
Global
configuration mode
voice-vlan default-oui resume
Restore all defualt OUI
configurations
Global
configuration mode
show voice-vlan oui
Display all defualt and user
OUI configuration
Privileged mode
voice vlan <1-4094>
(enable|disable)
Interface enable Voice VLAN
Interface
configuration mode
voice vlan qos map-queue
<0-7> remark-dscp <0-63>
The interface configuration
QoS priority, default queue is
6, DSCP is 46
Interface
configuration mode
no voice vlan qos
Restore interface QoS priority
default configuration
Interface
configuration mode
no voice vlan
Delete interface configuration
Voice VLAN
Interface
configuration mode
show voice-vlan state
Display all interfaces
configured with Voice VLAN
Privileged mode
6.6 VLAN mapping
The VLAN mapping (i.e., VLAN Mapping) function can modify the message carried VLAN
Tag, providing the following mapping relationship: 1:1 VLAN mapping: the message carrying
VLAN Tag in VLAN ID is modified to another VLAN ID。
Before configuring the VLAN map, the corresponding VLAN must be created first。
command
describe
CLI mode
vlan-mapping vlan <1-4094>
map-vlan <1-4094>
A VLAN mapping relation for
configuring ports
Interface
configuration mode
no vlan-mapping vlan
<1-4094>
A VLAN mapping relation for
deleting ports
Interface
configuration mode
no vlan-mapping
All VLAN mapping
relationships for deleting ports
Interface
configuration mode
show vlan-mapping
Display the VLAN mapping of
all configurations
Privileged mode
