94 / 322
The user can preset the OUI address or use the default OUI address as the judgment standard,
as follows
Serial number OUI address Manufacturer
1 0001-e300-0000 Siemens phone
2 0003-6b00-0000 Cisco phone
3 0004-0d00-0000 Avaya phone
4 00d0-1e00-0000 Pingtel phone
5 0060-b900-0000 Philips/NEC phone
6 00e0-7500-0000 Polycom phone
7 00e0-bb00-0000 3com phone
Manually add IP access port to Voice VLAN。Then, by identifying the source MAC of the
message and matching the OUI address, after the match is successful, the system will send priority
to the ACL rules and configuration messages。
Voice VLAN security mode and common mode, safe mode：Only OUI matched language
streams are allowed to be transmitted in Voice VLAN, while OUI mismatched data streams are
not allowed to be transmitted in Voice VLAN；Normal mode: All data streams can be transmitted
in the voice VLAN。
Before configuring Voice VLAN, you must first create the corresponding VLAN。
command
describe
CLI mode
voice-vlan security
(enable|disable)
Voice VLAN security mode
enable
Global
configuration mode
voice-vlan oui WORD mask
WORD
Configuring user OUI
Global
configuration mode
voice-vlan oui WORD mask
WORD description WORD
Configure user OUI and name
Global
configuration mode
no voice-vlan oui WORD
mask WORD
Deleting user OUI
configuration through OUI
address and mask
Global
configuration mode
no voice-vlan oui description
WORD
Delete user OUI configuration
by name
Global
configuration mode
no voice-vlan oui
Delete all user OUI
configuration
Global
configuration mode
no voice-vlan default-oui
WORD mask WORD
Deleting defualt OUI
configuration through OUI
address and mask
Global
configuration mode
no voice-vlan default-oui
Delete defualt OUI
Global
