Eighteenth chapters

TCP/IP basic configuration

For a two layer switch with network management function, it is necessary to provide the

basic network configuration for TCP/IP protocol and realize the communication function with

other devices。

The main contents of this chapter are as follows：

 Configuring the VLAN interface

 Configuring ARP

 Configuring static routing

 TCP/IP basic configuration example

18.1 Configuring the VLAN interface

In the switch, each three layer interface is attached to a certain VLAN, so the three layer

interface is also called VLAN interface. The creation and deletion of the VLAN interface is

accomplished manually. switches can be divided into 4094 VLAN at most, but at most 32 subnets

can be built. The creation of subnet interface can be created according to the needs of users; the

subnet interface can be deleted manually by users, and can be deleted with the deletion of the

VLAN in which the subnet is located。

Each VLAN interface has a name. The name of the VLAN interface is the string "VLAN",

followed by the VLAN ID number, such as the name of the three layer interface of VLAN 1 is

"vlan1", and the name of the three layer interface of VLAN 4094 is "vlan4094"。
