Like ports, the VLAN interface also has management status and link state. At present, the
switch does not provide the configuration of the management state of the VLAN interface. As
long as the VLAN interface is established, the management state of the VLAN interface is always
UP. Link state VLAN interface is corresponding to the interface of the VLAN contained in the
port, as long as the link state of a port in VLAN is RUNNING, then the link state of the VLAN
interface is RUNNING, if VLAN in all ports are not RUNNING, then the link state of the VLAN
interface is not RUNNING。
On the VLAN interface, you can configure the IP address and indicate the network prefix of
the network segment connected to the interface (converted to network mask). Currently, switches
only support one IP address on one VLAN interface. Before configuring the IP address, users need
to create the VLAN first and add the related ports to the VLAN. By default, the switch has the
interface of VLAN1, and the IP address 192.168.0.1/24 is set on this interface, and the user can
also modify the IP address of the VLAN1 interface. The VLAN interface other than VLAN1
defaults not to set the IP address。
The commands for configuring the IP address of the VLAN interface are as follows：
command
describe
CLI mode
Ip interface vlan <2-4094> Create a VLAN interface
Global
configuration
mode
No Ip interface vlan
<2-4094>
Deleting a VLAN interface
Global
configuration
mode
ip address <ip-prefix>
Set the IP address on the VLAN
interface. Parameters include the
IP address of the interface and the
network prefix of the connected
segment. If the VLAN interface
originally exists the IP address,
first delete the original IP address,
and then set the specified IP
address. The format of the
parameter is A.B.C.D/M
。
Interface
configuration
mode
no ip address [ip-prefix]
Deleting the IP address of the
VLAN interface. If the parameter
is specified, the parameter must
Interface
configuration
mode
