295 / 322
oam enable
Open Ethernet OAM function, default
Ethernet OAM function is closed。
Interface
configuration
mode
oam loopback
Enable Ethernet OAM loopback
function. Default Ethernet OAM
loopback function shutdown。
Interface
configuration
mode
no oam loopback
Turn off Ethernet OAM loopback
function. Default Ethernet OAM
loopback function shutdown。
Interface
configuration
mode
show oam configuration
Displays the window and threshold of
general link events。
Privileged
mode
show oam local-state (IFNAME|)
View OAM local information
Privileged
mode
show oam remote-state (IFNAME|)
View OAM peer to peer information
Privileged
mode
show oam link-event (IFNAME|)
View OAM link event information
Privileged
mode
show oam-loopback IFNAME
Display loopback information of a port。
Privileged
mode
25.3 Typical configuration examples of OAM
1 Networking requirement
By configuring the Ethernet OAM protocol on Device A and Device B, the data link layer is
managed; (Device A port: fe1/1, Device B port: fe1/1)
(1) Configuration Device A：
Switch>enable
Switch#configure terminal
Switch(config)# interface fe1/1
On port Ethernet1/0/1, configure its Ethernet OAM connection mode as passive mode, and enable
Ethernet OAM function。
Switch(config-fe1/1)#oam mode passive
Switch(config-fe1/1)#oam enable
(2) Configuration Device B:
Switch>enable
Switch#configure terminal
Switch(config)# interface fe1/1
The Ethernet OAM working mode of configuring port Ethernet1/0/1 is default mode active, and
can make Ethernet OAM function。
