158 / 322

Switch(config-xe1/1)# switchport mode trunk

Switch(config-xe1/1)# switchport trunk allowed vlan add 3

Switch(config-xe1/1)# switchport trunk allowed vlan add 4

Switch(config-xe1/1)# switchport trunk allowed vlan add 5

Switch(config-xe1/1)# switchport trunk allowed vlan remove 1

Switch(config-xe1/1)#exit

Switch(config)# interface xe1/3

Switch(config-xe1/3)# switchport mode trunk

Switch(config-xe1/3)# switchport trunk allowed vlan add 3

Switch(config-xe1/3)# switchport trunk allowed vlan add 4

Switch(config-xe1/3)# switchport trunk allowed vlan add 5

Switch(config-xe1/3)# switchport trunk allowed vlan remove 1

Switch(config-xe1/3)#exit

Configure ERPs instance 1, ERPs sub ring 2

Switch(config)#erps 1

Switch(config-erps-1)#ring 2

Switch(config-erps-1)# ring 2 ring-mode sub-ring

Switch(config-erps-1)# ring 2 node-mode rpl-owner-node

Switch(config-erps-1)# ring 2 raps-vlan 3

Switch(config-erps-1)# ring 2 traffic-vlan 4

Switch(config-erps-1)# ring 2 traffic-vlan 5

Switch(config-erps-1)# ring 2 rpl-port xe1/1

Switch(config-erps-1)# ring 2 rl-port xe1/3

Switch(config-erps-1)# ring 2 enable

Switch(config-erps-1)#exit

10.6.3 Multi instance load balancing example

The following diagram, SW1, SW2, SW3 and SW4 nodes constitute a ERPs instance 1 single

loop ring1, 1, 3 ports of each node as the ERPs ring ring port, protocol VLAN is 2, 3, 4 VLAN

data, the SW1 node is RPL owner node, SW2 node is RPL neighbor node, link and SW1 SW2 for

RPL link。

SW1, SW2, SW3 and SW4 nodes constitute a ERPs instance 2 single loop RING2, 1, 3 ports

of each node as the ERPs ring ring port, protocol VLAN is 5, 6, 7 VLAN data, the SW1 node is

RPL owner node, SW4 node is RPL neighbor node, link between SW4 and SW1 for the RPL link。
