85 / 322
switchport mode hybrid
The VLAN mode of the
specified port is HYBRID
mode. After executing this
command, the port is the
untagged member of VLAN1,
and the default VLAN of the
port is 1
。
Interface
configuration
mode
no switchport hybrid
The VLAN mode of the port is
no longer HYBRID mode,
back to the default, that is, the
ACCESS mode
。
Interface
configuration
mode
6.2.3 VLAN configuration of ACCESS mode
Before the port is configured for VLAN, the VLAN mode of the port should be specified as
the ACCESS mode。In this VLAN mode, the port defaults to the VLAN1 member of untagged,
and the default VLAN of the port is 1。The VLAN configuration command of ACCESS mode is as
follows：
command
describe
CLI mode
switchport access vlan
<vlan-id>
The configuration port is the
untagged member of the
specified VLAN, and the
default VLAN of the port is the
specified VLAN. Parameters
range from 2 to 4094
。
Interface
configuration
mode
no switchport access vlan
The VLAN configuration of
the port goes back to the
default, that is, the port is the
untagged member of VLAN1,
and the default VLAN of the
port is 1
。
Interface
configuration
mode
