246 / 322

switches support RFC, BRIDGE, and private MIB objects, and can fully manage switches

through SNMP. Some MIB:RFC 1213, RFC 1493, RFC 1724, RFC 1850, RFC 1907, RFC 2233,

RFC 2571, RFC 2572, RFC 2575, RFC 2573, RFC 2574, are listed below ，

RFC 2674 and other common MIB.

Figure is an example of SNMP protocol interaction between management workstation and

management agent. Management workstation can access switch management agent SNMP

message sent by Get Request, GetNext Request, GetBulk Request and Set Request, gets or sets the

exchange value of the MIB object, Get Response switch management agency send SNMP

message to the management station. When there are some events on the switch, the management

agent of the switch sends the SNMP TRAP message to the management workstation。

SNMP protocol interaction between management workstation and management agent

19.2 SNMP configuration

The SNMP configuration includes the community configuration of the switch, the

configuration of the TRAP workstation, the information of the SNMP system, and the

configuration of group engine, ID, user and snmpV3. The switch has a read-only shared default,

and the share name is public. The switch can configure up to 8 shares。The switch does not

configure TRAP workstations by default. The switch has a default local engine ID, and the switch

can modify the local engine ID. The switch has a default user name:initialnone, which belongs to a

non identified unencrypted user name. The switch can configure multiple different levels of user

names. The switch has a default group name:initial, and switches can configure different group

name according to different user names。

The commands of SNMP are as follows：

command

describe

CLI mode

snmp community

<community-name> {ro | rw}

Configure the name of the

shared object that accesses the

network management, which is

an interactive command. When

configuring, the user can input

the created name of the shared

body and read / write

Global

configuration

mode
