the processing, otherwise the
VLAN is created。Parameters
range from 2 to 4094。
no vlan <vlan-id>
Delete a VLAN, if the VLAN
does not exist, do not do
processing, otherwise delete
the VLAN
。Parameters range
from 2 to 4094。
VLAN
configuration mode
6.2.2 Configuring port VLAN mode
Before configuring the port VLAN, you need to specify the VLAN mode of the port. By
default, the VLAN mode of the port is ACCESS mode。The VLAN mode command of the
specified port follows the table：
command
describe
CLI mode
switchport mode access
The VLAN mode of the
specified port is ACCESS
mode
。After executing this
command, the port is the
untagged member of VLAN1,
and the default VLAN of the
port is 1。
Interface
configuration
mode
switchport mode trunk
The VLAN mode of the
specified port is TRUNK
mode. After executing this
command, the port is the
tagged member of VLAN1,
and the default VLAN of the
port is 1
。
Interface
configuration
mode
no switchport trunk
The VLAN mode of the port is
no longer TRUNK mode, back
to the default, that is, the
ACCESS mode
。
Interface
configuration
mode
