106 / 322
qos {dscp-based| cos-based|
dscpcos-based|
apply-policy <1-256>}
Enable port QoS function。
Interface
configuration mode
no qos
Restore default port-based。
Interface
configuration mode
show qos
Display configuration
information for all QoS
Privileged mode
show qos interface IFNAME
Display interface configuration
of QoS information
Privileged mode
show qos interface
Display the QoS information
of all interface configurations
Privileged mode
7.2.6 Configuring the port user priority (COS value)
command
describe
CLI mode
qos user-priority <0-7>
Configuring the user priority
(COS value) of the port
Interface
configuration mode
no qos user-priority
The user priority (COS value)
of the recovery port is the
default configuration
。
Interface
configuration mode
7.3 Example of basic QoS configuration
Configuring the ge1/3 user priority (COS value) is 3, and the COS based QoS function
defaults to boot：
Switch#configure terminal
Switch#(config)#interface ge1/3
Switch#(config-ge1/3)#qos user-priority 3
Switch#(config-ge1/3)#end
Configure the interface ge1/3 to start the DSCP based QoS function and map the DSCP value
3 to the priority queue 2：
Switch#configure terminal
Switch#(config)#qos dscp-map-qp 3 qosprofile qp2
Switch#(config)#interface ge1/3
Switch#(config-ge1/3)#qos dscp-based
