201 / 322
14.1 MVR profile
Multicast VLAN registration (MVR) is applied to multicast streaming applications in service
provider networks, such as vod. MVR allows users to subscribe to or cancel multicast flows within
the multicast VLAN, allowing a multicast VLAN to share data streams with other VLAN. MVR
has two purposes: (1) through simple configuration, it can effectively and securely transfer
multicast flows between VLAN; (2) support multicast groups dynamically join and leave；
MVR is similar to IGMP snooping in that two functions can be started at the same time,
MVR only handles the joining and leaving of configured multicast groups, and the other groups
join and leave by IGMP snooping management. The difference between them is that multicast
flows in IGMP snooping can only be forwarded within one VLAN, while MVR multicast streams
can be forwarded in different VLAN。
14.2 configuration MVR
command
describe
CLI mode
mvr (enable|disable) Start global MVR
Global
configuration mode
no mvr Clear all MVR configurations
Global
configuration mode
mvr group A.B.C.D
Configuring IP multicast
address
Global
configuration mode
no mvr group A.B.C.D Delete IP multicast address
Global
configuration mode
mvr group A.B.C.D <1-256>
Configure the IP multicast
address and configure a
continuous MVR group
Global
configuration mode
