Switch(config-ge1/2)#switchport mode access

Switch(config-ge1/2)#switchport access vlan 2

Switch(config-ge1/2)#exit

Switch(config)#interface ge1/3

Switch(config-ge1/3)#switchport mode access

Switch(config-ge1/3)#switchport access vlan 3

2) Troubleshooting

Inter switch VLAN, within the same VLAN PC can communicate, if not. Must see below：

 Connect the PC port is belong to the corresponding VLAN, and the application of

ACCESS model to join the VLAN。

 The cascade port 1/1 is added to each VLAN, and port 1/1 is TRUNK mode。

6.4 MAC, IP subnet, protocol VLAN

VLAN based on MAC is based on the source text MAC address to be divided。After

receiving the untagged (or tag 0) message from the port, the VLAN of the message is determined

according to the source MAC address of the message, and then the message is automatically

divided into the designated VLAN transmission；

VLAN based on IP subnet is divided according to IP address and subnet mask of newspaper

source。After receiving the untagged message from the port, the VLAN of the message is

determined according to the source address of the message, and then the message is automatically

divided into the designated VLAN transmission。This feature is mainly used to send messages

from designated network segments or IP addresses in specified VLAN；

Protocol based VLAN assigns different VLAN ID to the message according to the protocol

type of the message received by the port。The protocols that can be used to divide VLAN are IP,

IPV6, IPX, etc.。

Before configuring VLAN based on MAC, IP subnet and protocol, the corresponding VLAN

must be created first。

command

describe

CLI mode

mac-vlan mac WORD vlan

<1-4094>

Create a VLAN based on the

source MAC address

Interface

configuration mode

no mac-vlan mac WORD

Deleting a VLAN based on the

source MAC address

Interface

configuration mode
