6.2.4 VLAN configuration of TRUNK mode
Before the port is configured for VLAN, the VLAN mode of the port should be specified
as the TRUNK mode。In this VLAN mode, the port defaults to the VLAN1 member of tagged, and
the default VLAN of the port is 1。The VLAN configuration command of TRUNK mode is as
follows：
command
describe
CLI mode
switchport trunk allowed vlan
all
The configuration port is the
tagged member of all VLAN.
For the newly created VLAN,
the port is also the tagged
member of these VLAN
。
Interface
configuration
mode
switchport trunk allowed vlan
none
Except for VLAN1, the port is
no longer a member of all
other VLAN tagged
。
Interface
configuration
mode
switchport trunk allowed vlan
add <vlan-list>
Configure the port to be the
tagged member of the
specified one or more VLAN
。
The parameter <vlan-list> can
be a VLAN, a VLAN range or
a plurality of VLAN。For
example, the parameters can
be "1", "2-4" or "1,3,5"。
Interface
configuration
mode
switchport trunk allowed vlan
remove <vlan-list>
The port is cleared from the
specified one or more VLAN
and is no longer the tagged
member of these VLAN
。The
parameter <vlan-list> can be a
VLAN, a VLAN range or a
plurality of VLAN。For
example, the parameters can
be "1", "2-4" or "1,3,5"。
Interface
configuration
mode
